FAAC B680 Boom Gate Sydney | Commercial Access Control

The FAAC B680 boom gate is a high-performance commercial boom gate and vehicle access control system designed for industrial, strata and high-traffic vehicle access applications.

Engineered for intensive daily operation, the B680 combines advanced hybrid technology, rapid opening speeds and intelligent safety features to deliver secure and efficient vehicle access management for warehouses, commercial facilities, apartment complexes, industrial sites and restricted vehicle entry environments. Designed for demanding environments, the FAAC B680 provides reliable high-cycle performance and seamless integration with modern access control systems.

Eco Traffic Solutions supplies and installs FAAC commercial boom gate systems across Sydney and NSW, delivering professional integration, preventative maintenance and ongoing support tailored to your operational requirements.

Boost your site’s security and efficiency with professional boom‑gate installation, maintenance and repairs across Greater Sydney. Eco Traffic Solutions delivers tailored traffic control systems, expert onsite setup and ongoing support—so you can enjoy reliable access management without the hassle.

Ready to get started?
Call 0434 276 600 today for a free quote
Or send us an enquiry by filling out the form below and our Sydney team will be in touch promptly!

Download Brochure

Download Manual

Send Your Enquiry

Description

Key Features

Hybrid Hydraulic System: Combines a 24V DC brushless motor with hydraulic technology, offering the benefits of both systems for enhanced performance and reliability.
High-Speed Operation: Achieves beam opening times ranging from 1.5 to 6 seconds, depending on the model and configuration.
Extended Beam Lengths: Supports boom lengths from 2 to 8 meters, accommodating various lane widths.
Durable Construction: Features an epoxy zinc anti-corrosion treatment and polyester painting, ensuring long-lasting durability.
Safety Features: Equipped with adjustable electronic anti-crushing safety mechanisms and a manual release for use during power outages.
High Duty Cycle: Designed for continuous use, capable of handling over 2 million cycles before requiring maintenance.
The multi-function E680S control board offers numerous programmable inputs and outputs, allowing for customized configurations to suit various access control needs

Technical Specifications

Power Supply: 100–240 V AC, 50/60 Hz
Motor: 36V DC brushless motor
Motor Power: 240VAC
Motor Speed: 1,000–6,000 rpm
Pump Flow Capacity: 3.2 l/min (max)
Torque: 0–370 Nm
Operating Temperature: -20°C to +55°C
Protection Class: IP56
Weight: Approximately 85 kg
